Panduit F92ELQ1Q1SNM2.5 OS2 Duplex Fiber Patch Cord

Product Description

The PANDUIT F92ELQ1Q1SNM2.5 is an OS2 single-mode duplex fiber optic patch cord designed for low-loss, high-bandwidth structured cabling installations. Built with a 1.6 mm duplex cable and polished PC (physical contact) connectors on both ends, this cord delivers reliable signal transmission in demanding network environments. The LSZH (low smoke zero halogen) jacket reduces toxic fume and smoke output in the event of a fire, making it the correct choice for installations in plenum-adjacent or enclosed-space applications where code compliance is a priority. It is terminated with push-pull LC connectors and measures 2.5 meters in length.

This patch cord is suited for data center, telecom room, and enterprise LAN deployments where OS2 single-mode fiber infrastructure is in place. The push-pull LC connector design simplifies dense panel installations by allowing extraction without requiring finger access around adjacent cables. It is installed by low-voltage technicians, network cabling contractors, and telecommunications professionals working with single-mode fiber distribution frames, patch panels, and active equipment ports.

Key Features

• OS2 single-mode fiber supports long-distance, high-bandwidth transmission
• 1.6 mm duplex cable construction for flexible routing in tight spaces
• PC-polished connectors minimize back reflection at mating interfaces
• LSZH jacket meets low smoke zero halogen requirements for enclosed and transit-space installations
• Push-pull LC connector design enables high-density panel management
• 2.5 meter length suits typical rack-to-rack and equipment-to-panel runs

Compatibility

Designed as an OEM-style patch cord for use with LC-port single-mode fiber patch panels, switches, transceivers, and fiber distribution frames in OS2 single-mode structured cabling systems.

Installation Notes

Installation should be performed by a qualified low-voltage or fiber optic cabling technician. Clean all mating ferrules with an appropriate fiber optic cleaning tool before insertion to prevent contamination-related signal loss. Do not exceed the minimum bend radius of the cable during routing or bundling. Follow TIA-568 and applicable local codes for fiber optic cabling installations in commercial and data center environments.
