Panduit F92ELLNSNSNM049 OS2 Duplex Lc Fiber Patch Cord

Product Description

The PANDUIT F92ELLNSNSNM049 is a single-mode OS2 duplex fiber optic patch cord terminated with LC connectors on both ends. Built with a 1.6mm low-smoke zero-halogen (LSZH) jacketed cable, this patch cord is designed for structured cabling installations where fire safety and low toxicity are required by code. The PC (physical contact) polish on the ferrules delivers reliable, low-loss connections suited for data center, enterprise LAN, and telecommunications backbone runs. Licensed electricians and low-voltage cabling technicians are the primary installers. The LSZH jacket meets plenum and riser specifications for environments where halogen-free materials are mandated.

This patch cord is suited for single-mode OS2 fiber optic network applications including horizontal and backbone runs in commercial buildings, data centers, and telecommunications rooms. The duplex LC format is a standard interface for SFP transceivers, optical switches, and patch panels in structured cabling systems. The LSZH jacket makes it appropriate for use in enclosed or poorly ventilated spaces where smoke and halogen emissions must be minimized under fire conditions.

Key Features

• OS2 single-mode fiber for long-distance, high-bandwidth optical transmission
• Duplex LC connectors compatible with SFP ports and standard fiber patch panels
• 1.6mm LSZH jacket for reduced smoke and halogen emissions in fire conditions
• Physical contact (PC) ferrule polish for low insertion loss and reliable signal performance
• 2-fiber duplex construction supports simultaneous transmit and receive paths

Compatibility

Designed as an OS2 single-mode duplex LC patch cord for use with LC-port fiber optic equipment, patch panels, and SFP transceivers in structured cabling systems meeting OS2 single-mode standards.

Installation Notes

Installation should be performed by a qualified low-voltage cabling technician or licensed electrician familiar with fiber optic termination practices. Before connecting, inspect ferrule end faces for contamination and clean per standard fiber handling procedures. Avoid sharp bend radii that exceed the cable minimum bend radius, as this can cause signal loss or damage the fiber. Follow all applicable codes including ANSI/TIA-568 structured cabling standards and local building codes governing LSZH cable use.
