Panduit F923RSNSNSNM011 OS2 Sc Duplex Fiber Patch Cable

Product Description

The PANDUIT F923RSNSNSNM011 is an OS2 single-mode duplex fiber optic patch cable with SC to SC connectors. It features a 3mm outer diameter jacket and houses 2 fibers in an OFNR-rated (Optical Fiber Nonconductive Riser) construction. This cable is designed for structured cabling installations where riser-rated optical runs are required between network equipment, patch panels, and distribution frames. Licensed low-voltage technicians and network infrastructure installers are the primary trades working with this product. The PC (physical contact) polish on the connectors ensures reliable signal transmission at single-mode wavelengths.

This patch cable is suited for commercial and enterprise network environments where OS2 single-mode fiber infrastructure is in place. Typical applications include horizontal and vertical riser runs between telecommunications rooms, equipment rooms, and data closets. The duplex SC connector configuration supports transceivers and switches that require a two-fiber send-and-receive path over single-mode fiber links.

Key Features

• OS2 single-mode fiber for long-distance, low-attenuation optical transmission
• Duplex SC to SC connectors with PC polish for reliable physical contact termination
• OFNR-rated jacket suitable for riser installations per NEC Article 770
• 3mm jacket diameter provides added mechanical protection in high-traffic pathways
• 2-fiber duplex construction supports full-duplex data transmission

Compatibility

Designed as an OEM-style replacement or standard patch cable for OS2 single-mode fiber infrastructure using duplex SC-terminated ports on switches, transceivers, patch panels, and media converters.

Installation Notes

Installation should be performed by a licensed low-voltage or structured cabling technician familiar with fiber optic handling practices. Never exceed the cable minimum bend radius during routing, as this can cause permanent fiber damage. Clean SC connectors with an appropriate fiber optic cleaning tool before insertion, and inspect end-faces with a fiber scope where possible. Riser installations must comply with NEC Article 770 requirements for the building type and occupancy.
