Panduit F923LSNSNSNM012 OS2 Sc Duplex Fiber Patch Cable

Product Description

The PANDUIT F923LSNSNSNM012 is an OS2 single-mode duplex fiber optic patch cable designed for low-loss, high-bandwidth structured cabling installations. The cable features SC connectors on both ends in a duplex configuration with a 3mm LSZH (Low Smoke Zero Halogen) jacket. The PC (Physical Contact) polish on each connector minimizes back-reflection and insertion loss. It ships as a single assembly and is suited for network technicians and low-voltage cabling installers working in data centers, enterprise networks, and telecommunications rooms.

This patch cable is used in OS2 single-mode fiber applications where halogen-free jacket materials are required by code or specification. LSZH jacketing is commonly mandated in plenum or enclosed-space installations such as transit facilities, tunnels, and multi-tenant commercial buildings. The duplex SC format supports full-duplex transceiver connections on switches, media converters, and fiber distribution panels. It is appropriate for both horizontal and backbone structured cabling runs where pre-terminated assemblies are specified.

Key Features

• OS2 single-mode fiber construction for long-distance, high-bandwidth transmission
• Duplex configuration with SC connectors on both ends for full-duplex links
• 3mm LSZH jacket reduces toxic smoke and halogen emissions in the event of fire
• PC (Physical Contact) polish on connectors reduces back-reflection at the mating interface
• Pre-terminated factory assembly for consistent performance and faster field deployment

Compatibility

Designed as an OEM-style replacement or standard-specification assembly for OS2 single-mode duplex SC-to-SC fiber patch connections in structured cabling systems.

Installation Notes

Installation should be performed by a qualified low-voltage or network cabling technician familiar with fiber optic handling procedures. Clean all SC connector ferrules with an appropriate fiber optic cleaning tool before mating to avoid contamination-related loss. Do not exceed the minimum bend radius of the cable during routing and dressing. Follow applicable standards such as ANSI/TIA-568 for structured cabling installations.
