Panduit F923LANSNSNM046 OS2 Duplex Fiber Patch Cable Sc Apc

Product Description

The PANDUIT F923LANSNSNM046 is an OS2 single-mode duplex fiber optic patch cable designed for low-loss, high-bandwidth structured cabling installations. Built with a 3mm LSZH (Low Smoke Zero Halogen) jacket, this cable is suited for use in plenum-sensitive or enclosed environments where fire and smoke safety standards apply. The cable features an SC APC connector on one end and an SC connector on the other, supporting polished physical contact terminations. Licensed electricians, low-voltage technicians, and network infrastructure installers work with this type of patch cable in both commercial and data center environments.

This patch cable is used in OS2 single-mode fiber networks running high-speed data transmission over extended distances. The SC APC to SC configuration makes it appropriate for fiber-to-the-premises (FTTP) distribution panels, patch panels, and telecommunications rooms where angled physical contact connectors are specified to reduce back-reflection. The LSZH jacket material meets codes requiring reduced toxic gas emissions in the event of fire, making it common in schools, hospitals, transit systems, and other public or confined-space installations.

Key Features

• OS2 single-mode fiber construction supports long-distance, high-bandwidth data transmission
• Duplex (2-fiber) configuration for simultaneous bidirectional signal paths
• 3mm LSZH outer jacket reduces smoke and toxic halogen emissions during fire exposure
• SC APC to SC connector pairing minimizes back-reflection at the angled physical contact end
• Physical contact (PC) polished ferrules on both ends for low insertion loss

Compatibility

Designed as an OEM-style replacement or new-installation patch cable for OS2 single-mode fiber patch panels, switches, and transceivers equipped with SC or SC APC ports.

Installation Notes

Installation is performed by licensed low-voltage technicians or structured cabling professionals. Inspect ferrule end-faces with a fiber inspection scope before mating connectors to avoid contamination-related signal loss. Do not exceed the minimum bend radius of the cable during routing. Follow TIA-568 and applicable local codes for fiber optic cabling installations in commercial and plenum-rated spaces.
