Panduit F91ER1NANSNM004 OS2 Lc Simplex Patch Cable

Product Description

The PANDUIT F91ER1NANSNM004 is an OS2 single-mode, single-fiber fiber optic patch cable with a 1.6mm diameter cable jacket and LC simplex connectors on each end. Featuring a physical contact (PC) polish on the ferrules and an OFNR (Optical Fiber Nonconductive Riser) rating, this patch cable is built for structured cabling installations where riser-rated fiber runs are required. It is designed for low-loss, single-mode transmission in data center, telecom room, and enterprise network environments. Licensed network technicians and structured cabling installers are the primary users of this cable.

This patch cable suits OS2 single-mode fiber infrastructure in horizontal and riser cable runs within commercial and enterprise buildings. The LC simplex form factor is widely used in high-density fiber patch panels, switches, transceivers, and media converters. The OFNR rating qualifies it for installation in building riser pathways between floors without the need for conduit in most jurisdictions.

Key Features

• OS2 single-mode fiber for long-distance, low-attenuation transmission
• LC simplex connectors with physical contact (PC) polish for reliable low-loss termination
• 1.6mm cable diameter for flexible routing in tight spaces and high-density enclosures
• OFNR-rated jacket meets riser fire code requirements for between-floor installations
• Single-fiber simplex configuration for unidirectional single-mode links

Compatibility

Designed as an OEM-style patch cable for use with LC simplex single-mode fiber ports on switches, transceivers, patch panels, and media converters in OS2 single-mode fiber cabling systems.

Installation Notes

Installation should be performed by a qualified structured cabling technician or network installer familiar with single-mode fiber handling procedures. Inspect ferrule end-faces before mating connectors and clean per manufacturer guidelines to avoid insertion loss. Verify riser pathway compliance with local building codes and NFPA 70 (NEC) Article 770 before routing OFNR-rated cable. Avoid sharp bend radii below the cable minimum bend radius specification to prevent signal degradation or fiber damage.
