Panduit f623rsnsnsnm038 OM1 Sc Duplex Fiber Patch Cord

Product Description

The PANDUIT f623rsnsnsnm038 is an OM1 multimode fiber optic patch cord designed for structured cabling installations in commercial and enterprise environments. It features a 2-fiber, 3mm jacketed construction with SC duplex connectors on both ends and standard polarity. The jacket carries an OFNR (Optical Fiber Nonconductive Riser) rating, making it suitable for installation in building riser pathways between floors. Network technicians and low-voltage cabling contractors install this patch cord to connect active equipment, patch panels, and fiber distribution units where 62.5/125 micrometer OM1 multimode glass is specified.

This patch cord is used in horizontal and vertical fiber runs within commercial buildings, data centers, and campus network closets. Standard polarity SC duplex terminations on both ends make it a straightforward connection in OM1 multimode links. The OFNR riser rating qualifies the jacket for use in vertical shaft and riser installations per applicable fire and building codes. It is well suited for connecting switches, media converters, and fiber patch panels in 62.5/125 multimode cabling plants.

Key Features

• OM1 62.5/125 micrometer multimode fiber construction
• 2-fiber, 3mm outer jacket for added durability and handling
• OFNR (Optical Fiber Nonconductive Riser) rated jacket for riser pathway installations
• SC duplex to SC duplex connectors with standard polarity
• PC (Physical Contact) polish on ferrules for low insertion loss

Compatibility

Designed as an OEM-style replacement or direct-use patch cord for OM1 multimode fiber optic cabling systems terminated with SC duplex connectors in riser-rated applications.

Installation Notes

Installation should be performed by a qualified low-voltage cabling technician or licensed network cabling contractor familiar with TIA-568 fiber optic standards. Before connecting or disconnecting fiber patch cords, ensure all active optical transceivers are powered down or ports are dark to prevent eye hazard from laser sources. Do not exceed the minimum bend radius of the cable during routing, and avoid sharp bends or kinks at connector boots. Inspect and clean ferrule end-faces with appropriate fiber optic cleaning tools before mating connectors.

Technical Specifications

• Fiber Type: OM1 62.5/125 micrometer multimode
• Number of Fibers: 2
• Jacket Diameter: 3mm
• Connector Type: SC Duplex to SC Duplex
• Polish Type: PC (Physical Contact)
• Jacket Rating: OFNR (Optical Fiber Nonconductive Riser)
• Polarity: Standard
• UNSPSC: 43223326
• UPC: 074983824182

Standard Information

• Brand: PANDUIT
• Manufacturer Part Number: f623rsnsnsnm038
