Panduit EV14-P47B-Q Insulated Vinyl Ring Terminal

Product Description

The PANDUIT EV14-P47B-Q is an insulated vinyl ring terminal designed for secure, reliable electrical connections in professional wiring applications. This type of terminal provides a closed-loop connection point that fastens under a screw or stud, keeping the conductor firmly seated. The vinyl insulation sleeve protects the crimped barrel from abrasion, moisture, and incidental contact with adjacent conductors. Electricians and wiring technicians use ring terminals like this to terminate stranded or solid wire in panel boards, junction boxes, and equipment enclosures where a captive, vibration-resistant termination is required.

This ring terminal is suited for residential, commercial, and light industrial electrical work. It is a standard choice when terminating conductors at grounding lugs, bus bars, terminal strips, or equipment chassis points where a bolt-down connection is needed. The insulated vinyl construction makes it appropriate for environments where basic insulation and color-coded wire gauge identification are part of standard installation practice.

Key Features

• Insulated vinyl sleeve provides electrical insulation and abrasion protection at the termination point
• Ring tongue design locks under a screw or stud for a captive, vibration-resistant connection
• Color-coded insulation supports quick visual wire gauge identification during installation
• Crimp-style barrel accepts standard hand or ratchet crimping tools for field installation
• Compact form factor suits panel boards, junction boxes, and equipment enclosures

Compatibility

Designed as an OEM-style ring terminal for use in standard residential and commercial electrical wiring applications where insulated vinyl crimp connectors are specified.

Installation Notes

Ring terminals of this type are installed by licensed electricians in accordance with NEC requirements. De-energize and lockout the circuit before terminating any conductor. Use a calibrated ratchet or hand crimping tool rated for the wire gauge and terminal size to ensure a gas-tight crimp. Do not solder over a crimped vinyl-insulated terminal, as heat can damage the insulation sleeve.

Technical Specifications

• Insulation Type: Vinyl
• Terminal Style: Ring (Closed Tongue)
• UPC: 61305636713

Standard Information

• Brand: PANDUIT
• Manufacturer Part Number: EV14-P47B-Q
