Panduit EDV10-250-Q Female Disconnect, PK25

Product Description

The Panduit EDV10-250-Q StrongHold female disconnect is vinyl barrel insulated and accommodates 12 to 10 AWG wires. It features a .250 x .032 tab size and is constructed with a tin-plated copper base material. This disconnect is suitable for use with CT-600-A, CT-1550, CT-1551, CT-2300/ST and CT-2500/L crimping tools.

• Metal insulation grip sleeve protects the crimp joint during high vibration applications.
• Internal barrel serrations assure good wire contact and maximum tensile strength.
• Internal wire stop assures proper length of insertion into terminal barrel.

Product Highlights

Panduit EDV10-250-Q female disconnect ensures a reliable connection with its insulated barrel and robust construction.

Product Information

Standard Information

• Brand: PANDUIT
• Manufacturer Part Number: EDV10-250-Q
• Country of Origin: Mexico

Technical Specifications

• Seam: Grip Sleeve, Butted
• Standards: UL Recognized, CSA, cULus, E78522, LR31212
• Max. Temp.: 194 Degrees F
• Wire Range: 12 to 10 AWG
• Max. Voltage: 600V
• Terminal Type: Crimp
• Insulation Dia: 0.23 in
• Overall Length: 1.03 in
• Insulation Type: Vinyl
• Insulation Color: Yellow
• Connection Material: Brass
• Base Material: Copper
• Finish/Coating: Tin-Plated
• AWG: 12-10
• Tab Size: .250 x .032
• Application: For use with CT-600-A, CT-1550, CT-1551, CT-2300/ST and CT-2500/L crimping tools
• Color: Yellow
• Conductor Size: 10 AWG
• Conductor Type: Stranded Copper
• Finish: Tin Plated
• Insulated: Vinyl Barrel Insulated
• Manufacturer Part Number: EDV10-250-Q
• Material: Copper
• Temperature Rating: 194 deg F
• Type: Type EDV
• Voltage Rating: 600 V
