Product Description
The PANDUIT C1.5WH6-F is a cover for wire ducts, featuring a snap-in design with a protective film. Constructed from general-purpose, lead-free PVC, it is suitable for indoor applications. The cover includes a non-slip liner to prevent sliding and has a UL 94 flame class of V-0.
- Protective film to protect the surface during storage, handling, and installation
- Non-slip liner to prevent cover slide
- General-purpose lead-free PVC material
- Suitable for use in indoor applications
- UL 94 flame class of V-0
Product Highlights
The C1.5WH6-F offers reliable protection and easy installation for wire management systems.
Product Information
Standard Information
-
Brand: PANDUIT
-
Manufacturer Part Number: C1.5WH6-F
-
Country of Origin: US - United States
Technical Specifications
-
Category: Cables, Wires - Management
-
Wire Ducts, Raceways: Wire Duct, Raceway Covers
-
For Use With/Related Products: Panduit Duct - Slotted, Solid and Round Hole - Types D1.5X, F1.5X, FS1.5X, G1.5X and S1.5X
-
Manufacturer: Panduit Corp
-
Height: 0.350" (8.89mm)
-
Series: PANDUCT
Type C
-
Width: 1.750" (44.45mm)
-
Length: 72.000" (182.80mm, 6.00')
-
Part Status: Active
-
Color: White
-
Accessory Type: Cover - Wire Duct, Snap In with Protective Film
-
Base Product Number: C1.5WH
-
Brand: Panduct
-
Standard: UL Recognized; CE Compliant; CSA Certified; RoHS Compliant; Flammability Rating of UL94V-0 after protective film is removed
-
Application: Cover for Wiring Duct with protective film to protect the surface during storage, handling, andinstallation.
-
Material: PVC
-
Mounting Type: Snap-On
-
Use With: Type G, Type F, Type D and Type FS Duct Base
-
Color Family: White
-
Applications: Indoor Applications
-
TC Connection: Snap-on
-
Type: Flush
-
Sub Brand: Panduct
-
Overall Length: 6 ft
-
CA Prop65 Warning: No
-
Prop 65: No
-
Standards Met: UL Recognized; Flammability Ratings: UL94 V-0; CSA Certified; CE Compliant; RoHS Compliant
