Panduit BSN18-C Splice Connector

Product Description

Panduit BSN18-C is a nylon insulated butt splice designed for connecting two solid or stranded wires. This connector is made for reliable performance in wiring applications. The internal wire stop helps ensure the correct insertion length, which provides a strong connection. The brazed seam design prevents the terminal barrel from splitting during the crimping process.

• Nylon insulated for durability
• UL and CSA rated for safety
• 600 volts rating for reliable electrical connections

Product Highlights

This butt splice is essential for repairs or extending existing wire connections. It is suitable for limited space applications due to its low-profile design.

Product Information

Standard Information

• Brand: Panduit
• Manufacturer Part Number: BSN18-C

Technical Specifications

• Conductor Size: 22 - 18 AWG
• Color: Red
• Material: Copper/Nylon
• Length: 1.15 inches
• Voltage Rating: 600 VAC
• Temperature Rating: 221 degrees Fahrenheit (105 degrees Celsius)
• Flammability Rating: UL 94 HB
• Standard Package Quantity: 100
