Panasonic FV-14ES1 Intelli-Balance 140 Elite Energy Recovery Ventilator (ERV) 30-140 CFM

Product Description

The PANASONIC FV-14ES1 Intelli-Balance Elite Energy Recovery Ventilator (ERV) series is ideal for multifamily units and new home build constructions. Customizable, these ERVs deliver high energy recovery performance achieving up to 89% SRE and are designed to meet Green Building Code standards. Engineered for total versatility and installation flexibility in temperate climate zones. The occupant-controlled boost function can move the ERV fan speed to maximum CFM when activated.

• All models can be adjusted for mirror installation and are equipped with a standard power cord and a hardwire adaptor kit.
• Two (2) powerful ECM motors with Smart Flow technology ensure optimum CFM output by overcoming static pressure to effectively remove contaminated air and replace with fresh air.
• Multi-speed selector (30 to 140 CFM) provides customizable airflow to create balanced, positive or negative pressure within the home.

Product Highlights

The Intelli-Balance Elite ERV features a multi-speed selector, ECM motors with Smart Flow technology and can be adjusted for mirror installation.

Product Information

Standard Information

• Brand: PANASONIC
• Manufacturer Part Number: FV-14ES1
• Country of Origin: Mexico

Technical Specifications

• MERV: MERV 13
• Air Flow Capacity (CFM): 140 30
• Min Airflow (CFM): 30
• Max Airflow (CFM): 140
• Energy Star Rated: Yes
• Duct Size: 6"
• Sensible Recovery Efficiency (SRE) (Heat)*: 140CFM/89%
• Total Recovery Efficiency (Cool)*: 140CFM/83%
• Model: FV-14ES1
• Model Number: Intelli-Balance Elite 140 (FV-14ES1)
• Sensible Recovery Efficiency (SRE): 89%
• Total Recovery Efficiency (TRE): 83%
• SKU: FV-14ES1
• BRAND: Panasonic
• CFM: 140, 30
• Product Type: HVAC Filter
• Collection: Intelli-Balance Elite ERV
