Packard TMJ270 Start Capacitor 270-324 MFD (Each) Replaces PMJ270

Product Description

The Packard TMJ270 is a start capacitor rated 270-324 MFD for 110-125 V AC motor starting applications. It is a dry, electrolytic, non-polarized capacitor designed for intermittent duty in single-phase motor start circuits and is compatible with potential and current relays. The unit meets EIA RS-463 type 2, operates at 50/60 Hz, and is rated for a 3-second start with up to 20 starts per hour.

• Capacitance 270-324 MFD, voltage rating 110-125 V AC, frequency 50/60 Hz
• Dry electrolytic, non-polarized construction for intermittent motor starting; rated 3-second start and 20 starts per hour
• Moisture- and oil-resistant molded phenolic resin or plastic round case with standard dual blade terminals

Product Highlights

Motor start capacitor for single-phase HVAC and compressor motors; meets EIA RS-463 type 2; operates -40 to 149 F (-40 to 65 C).

Product Information

Standard Information

• Brand: PACKARD
• Manufacturer Part Number: TMJ270
• Country of Origin: China

Technical Specifications

• Brand: Packard
• Manufacturer Part Number: TMJ270
• Replaces: PMJ270
• Unit: Each
• Capacitance: 270-324 MFD
• Voltage Rating: 110-125 V AC
• Frequency: 50/60 Hz
• Type: Start capacitor
• Phase: Single phase
• Function: Motor start
• Operating Temperature: -40 to 149 F (-40 to 65 C)
• Rated start: 3-second start
• Starts per hour: 20 starts per hour
• Case Material: Moisture- and oil-resistant molded phenolic resin or plastic
• Terminals: Standard dual blade terminals
• Standard: Meets or exceeds EIA RS-463 type 2
• Condition: New
• UPC: 840899129556
• Country of Origin: China
