Packard OV45-440 Run Capacitor 440/370V

Product Description

The Packard OV45-440 is a motor run capacitor suitable for AC motor applications. This unit operates efficiently at a voltage of four hundred forty/three hundred seventy volts and a frequency of sixty/fifty hertz. The capacitor is made with heavy-edged metalized polypropylene film dielectric, and it is housed in a durable aluminum case. It features a proprietary bio-degradable oil that prevents corrosion and enhances heat transfer.

• Operating life of up to sixty thousand hours
• Compliant with EIA-456-A and IEC 60252-1:2001 standards
• UL-approved pressure-sensitive interrupter included

Product Highlights

The OV45-440 is designed to withstand various temperatures and is equipped with advanced safety features. It operates in temperature ranges from minus forty degrees Celsius to seventy degrees Celsius. The capacitor includes a second-generation anti-explosion safety switch, ensuring safety during operation.

Product Information

Standard Information

• Brand: Packard
• Country of Manufacture: United States

Technical Specifications

• Voltage: 440/370 V
• Microfarad: 45/10
• Frequency: 60/50 Hz
• Maximum Working Temperature: 70 C
• Minimum Working Temperature: -40 C
• Case Material: Aluminum
• Capacitor Shape: Round
• Weight: 0.740 LB
• Dimensions: Depth 1.77 in., Height 4.45 in., Width 2 in.
