Packard D1100 Fasco Motor 1/50 HP Replacement Fasco/D1100

Product Description

The Packard D1100 is a shaded pole motor with a power rating of 1/50 HP. This motor is suitable for blower and air handler applications. It operates efficiently at 115 volts and 60 hertz, making it ideal for various HVAC systems. The D1100 model offers two speed options of 1550 and 900 RPM and includes features such as automatic thermal protection and sleeve bearings for improved functionality.

• 1/50 HP shaded pole motor
• Two speeds: 1550/900 RPM
• Automatic thermal protection

Product Highlights

Product Information

Standard Information

• Brand: Packard
• HP: 1/50

Technical Specifications

• RPM: 1550-900
• Frame: 3.3 inches
• Voltage/Phase: 115V (Single Phase)
• Motor Type: Shaded Pole
• Volts: 115
• Amps: 1.2/.7
• Hz: 60
• Phase: Single Phase
• Thermal Protection: Automatic
• Speeds: 2
• Rotation: CW Shaft End
• Bearings: Sleeve
• Motor Diameter: 3.3 inches
• Motor Length: 2 7/8 inches
• Shaft: 5/16 X 2 3/8 inches
• Bolt Circle: 2-27/32 (2.85 inches)
