Packard 80600 Vent Fan Motor - 3.3 Inch Diameter

Product Description

The Packard 80600 is a single-phase vent fan motor designed for use in furnaces. It features a shaded pole design and sleeve bearings. Operating at 115 volts and 60 hertz, this motor delivers a rated speed of 3000 RPM with an output of 1/80 horsepower. The full load amperage is 0.65. The rotation can be determined by viewing the shaft end. This model incorporates automatic overload protection and has thermal protection for enhanced safety. Various mounting options include belly band and thru bolt. The motor has a diameter of 3.3 inches and features a 1/4 inch diameter shaft with a length of 2.125 inches.

• Operates at 115 volts and reaches a speed of 3000 RPM.
• Includes automatic overload protection to safeguard against overheating.
• Supports multiple mounting options for easy installation.

Product Highlights

Reliable blower motor suitable for HVAC applications with thermal and overload protection features.

Product Information

Standard Information

• Brand: Packard
• Model: 80600

Technical Specifications

• Diameter: 3.3 inches
• Voltage: 115 volts
• Speed: 3000 RPM
• Power Output: 1/80 HP
• Full Load Amperage: 0.65
• Mounting Options: Belly band, thru bolt
• Thermal Protection: Automatic
• Standard Mounting Position: Horizontal only
