Packard 70855 Permanent Split Capacitor Motor 1/4 HP 208-230V

Product Description

The Packard 70855 is a single-phase permanent split capacitor motor designed for HVAC applications. Operating at 208-230 volts and 60 Hertz, this motor provides 1/4 horsepower at a speed of 1050 revolutions per minute. Rated for a current of 1.5 amperes, it features an open air over enclosure and includes automatic overload protection.

• Class 'A' insulation for thermal protection
• Reversing plug included for easy direction changes
• Thru-bolts supplied for installation

Product Highlights

With a service factor of 1.00 and suitable for ambient temperatures up to 40 degrees Celsius, the Packard 70855 motor is versatile and reliable. The shaft measures 1/2 inch in diameter and 6 inches in length, making it compatible with a variety of applications.

Product Information

Standard Information

• Brand: Packard
• MPN: 70855

Technical Specifications

• HP: 1/4
• Voltage: 208-230
• RPM: 1050
• AMPS: 1.5
• Phase: 1
• Rotation: Reversible
• Frame: 42
• Enclosure: Open Air Over
• Shaft Dimensions: 1/2 x 6.00
• Frequency: 60Hz
• Diameter: 5.0
• Length: 3.67
• Bearings: Sleeve
• Weight: 12
