PACKARD 6CW115 Refrigeration Condenser Fan Motor 115 Volts 6 Watts

Product Description

The PACKARD 6CW115 is a refrigeration condenser fan motor made for cooling applications. This motor runs on 115 volts and consumes 6 watts. It draws a current of 0.40 amps while delivering a speed of 1550 RPM at a frequency of 60/50 Hertz. The direction of rotation is clockwise when viewed from the shaft end. It is built with a totally enclosed (TEAO) cast iron enclosure, ensuring durability and protection.

• Operates at 115 volts and consumes 6 watts of power.
• Features a threaded shaft with a diameter of 1/4 inch and a length of 1/2 inch.
• Constructed with a cast iron body for enhanced durability.

Product Highlights

This motor is ideal for refrigeration systems needing reliable performance and protection against environmental factors.

Product Information

Standard Information

• Brand: PACKARD
• MPN: 6CW115

Technical Specifications

• Watts: 6
• Voltage: 115
• Current Draw: 0.40 Amps
• Rotation: CW (from opposite shaft end)
• Speed: 1550 RPM
• Frequency: 60/50 Hertz
• Enclosure Type: Totally Enclosed (TEAO)
• Material: Cast Iron
• Length Less Shaft: 2-7/8 inches
• Shaft Length: 1/2 inch
• Shaft Diameter: 1/4 inch
• Threaded Shaft: 1/4 x 20
