Packard 69317 1/7 HP, 120 VAC 60 Hz 1-Phase, 4.3 A, 1100 RPM, 1-Speed, 5 x 5.28

Product Description

The Packard 69317 is a reliable motor designed for various HVAC applications. This motor operates at one seventh of a horsepower and functions on a 120 Volt AC power supply with a frequency of sixty Hertz. It provides a single speed output at one thousand one hundred revolutions per minute. This motor is built with class B insulation and a metal frame that ensures durability.

• Power rating: 1/7 HP
• Automatic overload protection system
• UL and CSA approved

Product Highlights

The Packard 69317 is suitable for use in blower applications where consistent performance is essential. It features a shaded pole design that enhances its efficiency.

Product Information

Standard Information

• Manufacturer: Packard
• Product ID: 46589

Technical Specifications

• Enclosure Type: Open
• Frame Size: NEMA 42
• Service Factor: 1
• Voltage Rating: 120 Volt AC 1-Phase
• Motor FLA: 4.3 Amp
• Speed Rating: 1100 RPM
• Mounting Type: Stud
• Bearing Type: Sleeve
• Shaft Size: 1/2 Inch Diameter x 2-5/8 Inch Length
• Diameter: 5 Inches
• Length: 5.28 Inches
