Packard 63110 3/4-1/2 HP 1625/1380rpm 115/230v Motor

Product Description

The Packard 63110 is a 5 5/8" diameter motor with 1/2-3/4 HP, operating at 115/230 Volts and 1625 RPM. It features reversible rotation, ball bearings, and thermal overload protection. Designed for stud/bracket mounting, this PSC type motor has Class F insulation and UL certification. It replaces Captive Aire 6311R.

• 5-5/8" Diameter
• Reversible rotation
• Stud/Bracket Mounting

Product Highlights

The Packard 63110 motor is suitable for various applications requiring a reliable and efficient motor.

Product Information

Standard Information

• Brand: PACKARD
• Manufacturer Part Number: 63110
• Country of Origin: CHINA

Technical Specifications

• H.P.: 1/2, 3/4
• Speeds: 1
• Rotation: Reversible
• Bearings: Ball
• Diameter (In.): 5-5/8
• Enclosure: Open
• Mounting: Stud/Bracket
• Overload Protection: Thermal
• Shaft Dimension (In.): .5 x 2.87
• Length Less Shaft (In.): 6.82
• Type: PSC
• Voltage: 115/230
• Insulation Class: F
• Certifications: UL
• Rated Motor Output Power: 1/2 HP
• Rated Motor Speed: 1625 RPM
• Rated Motor Voltage: 115V, 230V
• Phase: 1
• Frequency: 60 Hz
• Frame: 48
• Number of Speeds: 1 Speed
• Frame Material: Rolled Steel
• NDE Bearing: Ball
• Shaft Diameter: 0.5"
• Shaft Length: 2.875"
• RPM: 1625
• Motor Voltage: 115/230
• NEMA Frame: 48
• Shaft ( in.): .5 in. x 2.87 in.
• phases: Single
