Packard 60825 Motor 1/6 HP (5-5/8 inch) Emerson 9735

PACKARD
Brand: PACKARD
SKU: 60825
Availability: In Stock

Ships same day if ordered by 12 pm
$114.61
$114.61
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

Packard 60825 is a 1/6 HP condenser fan motor rated for 208-230 VAC and 825 RPM. It is a permanent split capacitor (PSC) single-phase motor with a totally enclosed air over (TEAO) enclosure, ball bearings, and F-class insulation. The motor provides reversible rotation, continuous duty (S1) with a 1.35 service factor, Rheem mounting, automatic overload protection, and a 1/2 in x 6-1/2 in shaft.

  • 1/6 HP PSC motor for 208-230 VAC operation at 825 RPM; single-phase, single speed
  • Totally enclosed air over (TEAO) enclosure with ball bearings, F insulation class, and automatic overload
  • Rheem mounting (48 frame), reversible rotation, continuous duty (S1), shaft: 0.5 in diameter x 6.5 in length

Product Highlights

1/6 HP PSC condenser fan motor; 208-230 VAC; 825 RPM; Rheem mounting; reversible rotation

Product Information

Standard Information

  • Brand: PACKARD
  • Manufacturer Part Number: 60825
  • Country of Origin: China
Technical Specifications
Brand
Packard
MPN
60825
Horsepower
1/6 HP
Voltage
208-230 VAC
RPM
825
Motor Type
Permanent split capacitor (PSC)
Phase
Single
Speeds
1
Frame
48
Enclosure Type
Totally enclosed air over (TEAO)
Bearing Type
Ball
Insulation Class
F
Duty
Continuous (S1)
Service Factor
1.35
Amps
1 - 1.1 A
Rotation
Reversible
Shaft Diameter
0.5 in (1/2 in)
Shaft Length
6.5 in (6-1/2 in)
Mounting Type
Rheem mounting
Protection
Automatic overload
Construction
Steel and copper components
Frequency
60 Hz
Country of Origin
CHN
Compatible Replacements
Emerson 9735; Emerson K55HXDUY1263; Emerson K55HXGCE8094; GE 3155; GE 3200; Rheem 51-20760-11; Rheem 51-20763-01; Rheem 51-20763-02; Trane MOT-11731; Trane MOT-6250; Trane MOT-6316; ICP 1162939; ICP 1690175; Lennox 65G6001; Lennox 92W51; Mars 03203; Mars 10403; Mars 10430; Mars 22403; US Motors K55HXDUY1263; US Motors K55HXGCE8094; US Motors LX7927; InterLink YSLB-130-8-B002
