PACKARD 2CW115 Condenser Fan Motor 115V 2W

Product Description

The PACKARD 2CW115 is a condenser fan motor designed for HVAC systems. It operates at a voltage of 115V and consumes 2W of power. The motor’s CW rotation is viewed from the opposite end of the shaft. It runs at a speed of 1550 RPM and draws current of 0.34 Amps. This model includes an aluminum unit bearing and features a 1/4 threaded shaft.

• Operates at 115V, consuming 2W with a CW rotation at 1550 RPM.
• Features a 1/4 threaded shaft and includes necessary mounting hardware.
• Equipped with 25 wire leads terminated with insulated ring terminals.

Product Highlights

This motor is suitable for various refrigerator models and serves as a replacement part for GE WX4X990, Whirlpool 833697, and Whirlpool W10822259.

Product Information

Standard Information

• Brand: PACKARD
• MPN: 2CW115

Technical Specifications

• Voltage: 115V
• Wattage: 2W
• Rotation: CW rotation as viewed opposite shaft end
• RPM: 1550
• Amps: 0.34 Amps
• Mounting Holes: Three mounting holes spaced 2-1/2 inches apart center to center
• Shaft: 1/4 threaded shaft
• Includes: Nut and washer included
• Wire Leads: 25 total with insulated ring terminals
