Oxbox J5AC5060A1000 Air Conditioner Condenser 60000 Btu 5 Ton 14.3 SEER2 R-454B Residential Split System

Product Description

The Oxbox J5AC5060A1000 is a 5-ton outdoor air conditioner condenser rated at 60,000 BTU/h and designed for residential split-system cooling applications. Operating on R-454B refrigerant and achieving a 14.3 SEER2 efficiency rating, this unit meets current DOE efficiency standards for new installations. It connects to a matching indoor air handler via standard refrigerant line sets and runs on a 208/230-volt, single-phase, 60 Hz power supply. Licensed HVAC technicians install and commission this unit as the outdoor component of a central air conditioning system.

This condenser is intended for residential central air conditioning applications where a high-capacity 5-ton outdoor unit is required. It pairs with a compatible R-454B indoor air handler to form a complete split system. The unit is factory charged with the system refrigerant charge required for the outdoor condensing unit and approximately 10 feet of tested connecting line set, reducing field refrigerant handling during a standard installation.

Key Features

• 60,000 BTU/h cooling capacity in a 5-ton configuration
• 14.3 SEER2 efficiency rating meets current DOE minimum efficiency requirements
• R-454B refrigerant — low global warming potential alternative to R-410A
• 208/230-volt, single-phase, 60 Hz operation with 36.9-amp minimum branch circuit ampacity
• Maximum branch circuit protection rating as specified per unit submittal documentation
• Factory refrigerant charge sized for outdoor unit plus 10 feet of connecting line
• Painted galvanized steel cabinet construction for corrosion resistance

Compatibility

Designed for use as the outdoor condensing unit in a residential R-454B split air conditioning system, paired with a compatible R-454B indoor air handler. Specific matched indoor unit combinations should be verified against Oxbox system matching tables prior to installation to confirm rated system efficiency.

Installation Notes

Installation must be performed by a licensed HVAC technician holding the appropriate EPA Section 608 certification for handling refrigerants. Disconnect and lock out all electrical power before making any electrical or refrigerant connections. The refrigerant line set must be leak-checked and fully evacuated before opening service valves, following ASHRAE and manufacturer evacuation guidelines. Verify local electrical codes for disconnect switch, wire sizing, and overcurrent protection requirements before energizing the unit.

Technical Specifications

• Cooling Capacity: 60,000 BTU/h (5 Ton)
• Efficiency Rating: 14.3 SEER2
• Refrigerant Type: R-454B
• Voltage: 208/230 volts
• Phase: Single Phase
• Frequency: 60 Hz
• Minimum Branch Circuit Ampacity: 36.9 amps
• System Control Voltage: 24 volts
• Unit Type: Outdoor Condensing Unit
• Cabinet Material: Painted Galvanized Steel

Standard Information

• Brand: Oxbox
• Manufacturer Part Number: J5AC5060A1000
