OSG 404-328111 Center Cutting Regular Length Single End Standard Square End Mill, 21/64 in Dia Cutter, 7/8 in Length of Cut, 4 Flutes, 3/8 in Dia Shank, 2-1/2 in OAL, TiAlN Coated

Product Description

The OSG CARBIDE 404-328111 is a center cutting regular length single end standard square end mill. It features a diameter of twenty-one sixty-fourths inches and a shank diameter of three eighths inches. This milling tool also has a flute length of seven eighths inches and an overall length of two and one-half inches. The four-flute design enhances cutting efficiency.

• Material: Carbide
• Coating: TiALN
• Flute Type: Spiral

Product Highlights

The OSG 404-328111 end mill is suitable for various milling tasks. It provides durability and precision in cutting operations. The TiALN coating allows for extended tool life and improved performance in metalworking applications.

Product Information

Standard Information

• Brand: OSG
• Part Number: OSG404328111

Technical Specifications

• Diameter: 0.3281 inches (21/64)
• Shank Diameter: 0.3750 inches (3/8)
• Flute Length: 0.8750 inches (22.225 mm) (7/8)
• Overall Length: 2.5000 inches (63.500 mm) (2 1/2)
• Number of Flutes: 4
• End Shape: Square End
• Cutting Direction: Right Hand
• Helix Angle: 30 degrees
