Osg 22618 Straight Flute Tap M5x0.80 Metric Coarse Hss

Product Description

The OSG 22618 is a straight flute bottoming tap designed for cutting internal M5x0.80 metric coarse threads in a variety of metals. With three flutes and a bottoming chamfer, it threads holes close to the bottom of a blind bore where plug or taper taps cannot reach. The tap is manufactured from high-speed steel and finished with an oxide coating that reduces friction and provides corrosion resistance during cutting operations. It has an overall length of 60 millimeters, a thread length of 16 millimeters, and a shank diameter of 5.5 millimeters. Licensed machinists, tool-and-die makers, and maintenance technicians use this tap for precision metric thread work.

The OSG 22618 is suited for tapping aluminum, cast aluminum, cast iron, low-carbon steel, medium-carbon steel, and high-carbon steel. Its straight flute geometry makes it appropriate for through-holes and short blind holes where chip evacuation is managed manually or with cutting fluid. The 2B class of fit produces a standard tolerance internal thread compatible with M5x0.80 metric fasteners. This tap is a Series 121 tool and is packaged individually.

Key Features

• Bottoming chamfer allows threading to the bottom of blind holes
• Three straight flutes for controlled chip formation in ferrous and non-ferrous metals
• High-speed steel construction withstands the heat and stress of production tapping
• Oxide coating reduces friction and resists corrosion during use and storage
• 2B class of fit for standard metric thread tolerance
• Right-hand thread direction for conventional tapping operations

Compatibility

Designed for use in any standard tap wrench, T-handle, or machine tapping setup that accepts a 5.5-millimeter shank. Produces M5x0.80 metric coarse internal threads conforming to standard 2B tolerance class.

Installation Notes

Always secure the workpiece and use an appropriate cutting fluid or tapping compound for the material being threaded. Ensure the tap is properly aligned perpendicular to the workpiece surface before starting to avoid tap breakage or thread distortion. Reverse the tap periodically to break chips when working in deeper holes. Tapping operations should be performed by qualified machinists or maintenance technicians following applicable shop safety procedures.
