Osg 215-1730 Jobber Drill Bit No. 17 Wire Size

Product Description

The OSG 215-1730 is a high-speed steel jobber-length drill bit designed for general-purpose drilling in a wide range of metalworking applications. It carries a Number 17 wire gauge size, corresponding to 0.1730 decimal inch (4.39 mm) in diameter. The 135-degree split point with web thinning reduces walking at entry and lowers thrust requirements compared to a standard 118-degree point. The bright, uncoated finish suits dry or flood-coolant operations. Overall length is 2-3/16 inches with a 1-1/8-inch flute length. Right-hand cutting direction with a slow spiral and tapered web configuration. Machinists, tool-and-die workers, and maintenance technicians reach for this bit when drilling ferrous and non-ferrous materials in production or repair settings.

The 215-1730 is suited for drilling steel, alloy steel, stainless steel, cast iron, aluminum silicate, nickel alloy, titanium, and titanium alloy. The 5xD flute-to-diameter ratio provides chip clearance in moderately deep holes. The straight-cylindrical shank seats in standard drill chucks, collet chucks, and drill press quills without adapters. This bit fits bench drills, knee mills, CNC machining centers, and hand-held drill motors used in fabrication shops, maintenance departments, and field service applications.

Key Features

• Number 17 wire gauge size: 0.1730 inch (4.39 mm) diameter
• 135-degree standard point with web thinning for reduced entry thrust and minimal walking
• Slow spiral flute with tapered web for improved rigidity in harder workpiece materials
• Bright, uncoated finish compatible with dry cutting or conventional coolant
• Straight-cylindrical shank fits standard drill chucks and collet chucks without adapters
• General-purpose Series 215 construction rated for steel, stainless steel, cast iron, titanium, and nickel alloys

Compatibility

Designed as a general-purpose jobber drill for use in standard drill chucks accepting a 0.1728-inch straight-cylindrical shank. Compatible workpiece materials include steel, alloy steel, stainless steel, cast iron, aluminum silicate, nickel alloy, titanium, and titanium alloy per OSG Series 215 specifications.

Installation Notes

Installation is performed by machinists or maintenance technicians using a standard keyed or keyless drill chuck. Ensure the shank is fully seated and the chuck is tightened before operation. Select spindle speed and feed rate appropriate for the workpiece material and machine type; consult published speeds-and-feeds tables for high-speed steel tooling. Inspect the cutting edges for chipping or wear before each use and replace if the point geometry is compromised.
