Osg 1023800 Straight Flute Tap 6-32 Unc Bottoming Hss

Product Description

The OSG 1023800 is a straight flute bottoming tap designed to cut 6-32 UNC internal threads in a wide range of ferrous and non-ferrous materials. It features three flutes ground from high-speed steel with a bright, uncoated finish. The bottoming chamfer allows threading close to the bottom of a blind hole, making it the correct choice when full thread depth near the base is required. Overall length is 2 inches with a thread length of 11/16 inches. The H3 thread limit provides consistent tolerance control for 2B class of fit applications. Licensed machinists, tool and die makers, and maintenance technicians are the primary installers.

This tap is suited for production and maintenance tapping operations on aluminum, cast aluminum, cast iron, low-carbon steel, medium-carbon steel, and high-carbon steel workpieces. The straight flute geometry works well in through-hole and shorter blind-hole applications where chip evacuation is manageable by backing out the tap periodically. It is commonly used in light manufacturing, machine shops, and field maintenance environments where 6-32 machine screw threads are required.

Key Features

• Bottoming chamfer for threading to the base of blind holes
• 3-flute straight flute design suited for a broad range of metals
• High-speed steel construction provides good wear resistance at standard cutting speeds
• H3 thread limit maintains consistent 2B class of fit tolerance
• Bright uncoated finish compatible with standard tapping fluids and cutting oils
• Right-hand thread direction, standard UNC form

Compatibility

Designed as an OEM-style replacement or direct-use tap for any application requiring 6-32 UNC internal threads machined to a 2B class of fit in aluminum, cast iron, or carbon steel workpieces.

Installation Notes

Tapping operations should be performed by a qualified machinist or maintenance technician using a properly aligned tap handle, tapping head, or machine spindle. Always apply an appropriate cutting fluid or tapping compound for the workpiece material to extend tool life and improve thread quality. Secure the workpiece firmly before starting and back the tap out periodically to break and clear chips when working in blind holes. Inspect the tap for chipping or wear before each use and retire damaged taps immediately to avoid broken taps in the workpiece.
