Ortronics LM4-LC24H-2A1UN M4 Cassette 24 Port Patch Panel

Product Description

The ORTRONICS LM4-LC24H-2A1UN is an Infinium Core M4 cassette-style patch panel designed for structured cabling installations supporting CAT6 and CAT6A network infrastructure. This 24-port cassette mounts into compatible M4 enclosure frames and provides a high-density termination point for horizontal cable runs in telecommunications rooms and data closets. Network technicians and low-voltage cabling contractors install this unit as part of an organized, maintainable patching architecture. The cassette format allows for modular replacement and reconfiguration without disturbing the full panel assembly, reducing downtime during moves, adds, and changes.

This cassette is suited for commercial and enterprise network installations where structured cabling must meet CAT6 or CAT6A performance standards. It fits into horizontal patch panel applications within data centers, server rooms, and building telecommunications rooms. The 24-port configuration handles a standard rack unit worth of connections, making it a common choice for floor-by-floor distribution frames and intermediate distribution frames in multi-story commercial buildings.

Key Features

• 24-port cassette format supports high-density structured cabling in limited rack space
• Compatible with CAT6 and CAT6A cabling infrastructure
• Modular M4 cassette design allows independent replacement without full panel removal
• Sold as a single unit (EA), suitable for incremental frame buildout
• Designed for telecommunications room and data closet horizontal cable termination

Compatibility

Designed as an OEM-style replacement and expansion cassette for Infinium Core M4 series patch panel enclosure frames supporting CAT6 and CAT6A structured cabling systems.

Installation Notes

Installation should be performed by a licensed low-voltage cabling technician familiar with TIA-568 structured cabling standards. Power down or disconnect any active equipment connected to the patch field before removing or inserting cassettes. Verify cassette seating in the M4 frame before re-terminating or patching active circuits. Follow local building codes and applicable BICSI guidelines for cable management and bend radius.
