Orbit Industries OF7610-SW Emt Compression Connector 4 Inch

Product Description

The ORBIT INDUSTRIES OF7610-SW is a steel, rain-tight, insulated compression-type connector designed to bond EMT thinwall conduit to electrical junction boxes and enclosures in wet and damp locations. Built to a 4-inch trade size, this connector meets the rain-tight test requirements of NEC 358.42 and 314.15 (2008 edition), making it a code-compliant choice for exposed or outdoor electrical installations. The steel construction provides the mechanical protection required for conduit terminations in demanding environments. A labor-saving design allows electricians to tighten the connector onto EMT conduit quickly without specialized tooling.

This connector is intended for use in residential and commercial electrical installations where EMT conduit must terminate at a junction box or enclosure in a wet location. Typical applications include outdoor panels, weatherproof enclosures, and any raceway installation subject to rain or moisture exposure. The insulated throat protects conductor insulation at the point of entry. Licensed electricians performing rough-in or service work in compliance with NEC Article 358 are the primary installers of this fitting.

Key Features

• Rain-tight compression design meets NEC 358.42 and 314.15 requirements for wet locations
• 4-inch trade size for large-diameter EMT thinwall conduit terminations
• Steel construction provides mechanical protection at the conduit-to-enclosure transition
• Insulated throat protects conductor insulation at the connector entry point
• Labor-saving design allows fast tightening onto EMT conduit without special tools

Compatibility

Designed as an OEM-style fitting for use with 4-inch trade size EMT thinwall conduit terminating at electrical junction boxes or enclosures in wet or damp locations.

Installation Notes

Installation should be performed by a licensed electrician in accordance with NEC Article 358 and local electrical codes. De-energize the circuit and verify the panel is locked out before making any conduit terminations at enclosures. Ensure the conduit end is reamed and free of burrs before seating the connector to avoid damaging conductor insulation. Do not overtighten the compression nut, as excessive force can deform the fitting or conduit.

Technical Specifications

• Trade Size: 4 inches
• Connector Type: Compression, Rain-Tight
• Conduit Type: EMT Thinwall
• Material: Steel
• Insulated: Yes
• Listing/Compliance: NEC 358.42, NEC 314.15 (2008)
• UPC: 835243051072

Standard Information

• Brand: ORBIT INDUSTRIES
• Manufacturer Part Number: OF7610-SW
