Omegaflex FGP-CS-500-100 Csst Gas Piping 0.5 in 100 Ft

Product Description

The OMEGAFLEX FGP-CS-500-100 is a 100-foot reel of CounterStrike corrugated stainless steel tubing (CSST) in the 0.5-inch nominal size. CounterStrike is a listed flexible gas piping system designed for the distribution of natural gas and propane in residential and light commercial buildings. The stainless steel corrugated core provides flexibility for routing through framing and tight spaces, while the yellow jacketing serves as the system's arc-fault mitigation layer. Licensed plumbers and gas fitters install this product as part of a complete CounterStrike piping system.

This reel is used in new construction and retrofit gas piping installations where flexible routing is required from a meter or manifold to appliances such as furnaces, water heaters, dryers, and ranges. The 0.5-inch size is suited to branch runs serving individual appliances in residential applications. This product replaces the former OMEGAFLEX part number OMFSS4500100.

Key Features

• Corrugated stainless steel core provides flexible routing without field bending tools
• Yellow arc-fault mitigation jacket is integral to the CounterStrike system design
• 0.5-inch nominal diameter suitable for residential appliance branch runs
• 100-foot reel allows single-reel coverage of most residential jobs
• Replaces legacy part number OMFSS4500100

Compatibility

Designed for use as part of the OMEGAFLEX CounterStrike CSST system. Fittings, manifolds, and termination hardware must be CounterStrike-compatible components. This tubing is not interchangeable with other manufacturers' CSST fittings or termination hardware.

Installation Notes

Installation must be performed by a licensed plumber or gas fitter in accordance with the applicable fuel gas code, including the International Fuel Gas Code (IFGC) and local amendments. Shut off the gas supply and verify zero pressure before making any connections. All CounterStrike CSST installations require bonding and grounding per the manufacturer's installation guide and local code requirements. Do not use pipe wrenches or tools that could damage the jacket or corrugations.

Technical Specifications

• Nominal Size: 0.5 inches
• Reel Length: 100 feet
• Material: Corrugated stainless steel with arc-fault mitigation jacket
• Gas Types: Natural gas and propane

Standard Information

• Brand: OMEGAFLEX
• Manufacturer Part Number: FGP-CS-500-100
