OIL EQUIPMENT MANUFACTURING 13412 TYC Genera Engine Oil Cooler

Product Description

The OIL EQUIPMENT MANUFACTURING 13412 TYC Genera Engine Oil Cooler is built to provide efficient cooling for engine oil. It features a reliable aluminum core with a core thickness of zero point six three inches, core length of twenty-one point seventy-three inches, and core height of fifteen point fifty-five inches. This cooler follows a crossflow design with a total of sixty tubes. The inlet measures one point four inches in diameter, while the outlet measures one point three inches, both utilizing hose clamp connections for secure fitting.

• Aluminum core dimensions: 21.73 inches x 15.55 inches x 0.63 inches
• Crossflow configuration with a total of 60 tubes for optimum cooling
• Inlet and outlet hose clamp connection type for easy installation

Product Highlights

The engine oil cooler is designed to meet OEM specifications, ensuring durability in performance. The EOC distance measures ten point ninety-eight inches, with the EOC inlet and outlet diameter at zero point thirty-nine inches.

Product Information

Standard Information

• Brand: OIL EQUIPMENT MANUFACTURING
• MPN: 13412

Technical Specifications

• Core Thickness: 0.63 inches
• Core Length: 21.73 inches
• Core Height: 15.55 inches
• Core Material: Aluminum
• Rows: 1
• Fin Count: 85 (every 4 inches)
• Tube Count: 16 (every 4 inches)
• Total Tube Count: 60
• Flow Configuration: Crossflow
• EOC Distance: 10.98 inches
• EOC Inlet Diameter: 0.39 inches
• EOC Outlet Diameter: 0.39 inches
• Inlet Diameter: 1.40 inches
• Outlet Diameter: 1.30 inches
• Inlet Connection Type: Hose Clamp
• Outlet Connection Type: Hose Clamp
• Fin Wave Height: 0.20 inches
• Fin Wave Pitch: 2.4 inches
• Bottom Header Dimensions: 1.94 x 16.18 inches
• Top Header Dimensions: 1.94 x 16.18 inches
