Product Information
- Diaphragm Gas Valve
- Type NC, Slow Opening Fast Closing, Straight-Through, Non-Offset, Solenoid Operated
- Nominal Size 1-1/4 Inch
- End Connection Threaded x Threaded
- End to End Distance 3-11/16 Inch
- Body Material Die-Cast Aluminum
- Temperature Rating 32 to 125 Deg F
- Pressure Rating 1/2 PSI
- Inclusions/Features Ground Terminal
- Application Atmospheric Boiler, Commercial Water/Rooftop Heater
- Applicable Standard UL, CSA
- Overall Dimension 5-5/16 Inch Width x 5-7/8 Inch Depth x 6-13/16 Inch Height
- Fuel Type Liquid Propane, Natural
- Mounting Position Upright (Horizontal)
- Connection Type 6 Inch Lead Wire
- Voltage Rating 120 Volt AC 60 Hertz
- Current Rating 0.13 Amp
- Power Rating 9 Watt
- Valve Operation Timing 5 Second (Open), 2 Second (Close)
