Oatey W9207TNO Tru Drain 1-1/4 in Offset Grid Drain

Product Description

The OATEY W9207TNO is a 1-1/4 inch offset grid drain designed for installations where a standard centered drain outlet is not practical. The offset configuration allows the drain body to align with the waste line while the grid sits flush with the finished surface, making it a workable solution when rough-in conditions limit placement options. This unit ships without an overflow, so it is suited for applications where an overflow port is not required by the fixture or installation layout. Plumbers and finish tradespeople typically handle this fitting during rough-in or finish plumbing on tubs, shower bases, or similar drain points.

The W9207TNO fits residential plumbing applications where a 1-1/4 inch drain outlet is specified. The no-overflow design is appropriate for shower pans, receptor bases, or specialty tub installations that do not incorporate an overflow assembly. The offset body geometry is useful when the waste arm cannot be repositioned to align directly below the drain grid centerline.

Key Features

• 1-1/4 inch outlet size accommodates standard residential drain piping at that nominal diameter
• Offset grid design allows drain positioning independent of the waste line centerline
• No-overflow configuration simplifies installation where an overflow port is not required
• Grid face provides straining function at the drain opening to limit debris entry

Compatibility

Designed as an OEM-style replacement or new-installation drain fitting for residential plumbing fixtures requiring a 1-1/4 inch offset grid drain without an overflow.

Installation Notes

Installation should be performed by a licensed plumber in accordance with local plumbing codes and the applicable edition of the IPC or state-adopted equivalent. Shut off the water supply and verify the fixture is depressurized before beginning drain work. Ensure the drain body is properly sealed to the fixture surface using the appropriate gasket or sealant per the fixture manufacturer instructions. Do not overtighten the drain locknut, as this can crack the drain flange or damage the fixture basin.

Technical Specifications

• Outlet Size: 1-1/4 inches
• Drain Type: Offset Grid Drain
• Overflow: None
• UPC: 041193003485

Standard Information

• Brand: OATEY
• Manufacturer Part Number: W9207TNO
