Oatey K2802PCPO Push Fit Straight Valve 1/2 in X 3/8 in

Product Description

The OATEY K2802PCPO is a chrome-plated solid brass push fit straight valve with a quarter-turn ball mechanism, designed for residential under-sink and appliance water supply shutoff applications. The valve connects 1/2-inch push fit (PF) inlet to a 3/8-inch OD compression outlet without solder, crimping, or threading. The push fit design locks tubing in place on insertion, giving plumbers and skilled DIYers a fast, reliable connection. Chrome plating provides a finished appearance suited for exposed installations under sinks and in vanity cabinets.

This valve is used in residential plumbing applications where a local shutoff is needed at the supply line for sinks, dishwashers, and ice makers. The push fit inlet is compatible with copper, CPVC, and PEX tubing at the 1/2-inch size. The quarter-turn ball mechanism allows full open or full close without a stem packing point of failure, which is a common callback issue with older compression stop valves.

Key Features

• Push fit inlet connection — no solder, glue, or crimping required
• Quarter-turn ball valve for fast, positive shutoff
• Compatible with copper, CPVC, and PEX tubing
• 1/2-inch PF inlet x 3/8-inch OD outlet configuration
• Solid brass body with chrome plating for corrosion resistance and finished appearance

Compatibility

Compatible with 1/2-inch copper, CPVC, and PEX tubing on the inlet side. The 3/8-inch OD outlet connects to standard compression supply lines for sinks, dishwashers, and ice makers.

Installation Notes

A licensed plumber or qualified tradesperson should shut off the main water supply and relieve line pressure before installation. Ensure tubing is cut square and deburred before inserting into the push fit fitting to achieve a proper lock and seal. Follow local plumbing code requirements, which may reference IPC or UPC standards for approved fitting types and materials. Do not use thread sealant or pipe dope on the push fit inlet.

Technical Specifications

• Inlet Size: 1/2 inches Push Fit (PF)
• Outlet Size: 3/8 inches OD
• Body Material: Solid Brass
• Finish: Chrome-Plated
• Valve Type: Quarter-Turn Ball Valve
• Configuration: Straight (In-Line)
• Compatible Tubing: Copper, CPVC, PEX
• Weight: 0.447 pounds
• UPC: 00046224051305

Standard Information

• Brand: OATEY
• Manufacturer Part Number: K2802PCPO
