Oatey 42289 130 Series Testable PVC Drain - Square Barrel Only

Product Description

The Oatey 130 Series Testable PVC Drain, MPN 42289, is designed for both residential and commercial applications. This drain connects seamlessly to a DWV system. The flange base can be secured to the subfloor using countersunk holes and an approved fastener.

This drain has a solvent weld connection and works with two or three inch pipes, adhering to ASTM standards. The base is made from durable PVC, allowing for a solid fit with both two inch and three inch Schedule 40 fittings. The strainer is engineered to meet required load and flow rates, ensuring reliability in shower installations. It comes with a 1/4 turn test plug that can withstand up to forty feet of head pressure.

• Size: 4.54 inches
• Shape: Square
• Connection Type: Solvent Weld

Product Highlights

The drain includes an improved clamp collar ring that fastens securely using hex bolts with brass inserts. Enhancements in weep holes and channels allow for adjusted height, accommodating various installation needs.

Product Information

Standard Information

• Type: Shower Drain
• Finish: Brushed Stainless Steel

Technical Specifications

• Pipe Size: 2 or 3 inches
• Cover Design: Snap-In
• Drain Orientation: Shower
