Oatey 39134 Ice Maker Outlet Box 1/4 Turn 3-1/4 x 2-1/2 x 4

Product Description

The Oatey 39134 is an Ice Maker Outlet Box designed for residential and commercial applications. This outlet box allows for quick and safe connections to ice makers and water dispensers. It features a shut-off valve that can be installed on either side and is made from high impact polystyrene for durability. The compact dimensions of this box, which are three and one-quarter inches in width, two and one-half inches in depth, and four inches in height, allow it to fit into tight spaces easily.

• Product Type: Ice Maker Outlet Box
• Installation: Right or left-hand configuration
• Standards: Complies with NSF 61 and other applicable standards

Product Highlights

This Ice Maker Outlet Box includes preloaded nails for easy installation and does not require a support bracket. It is designed to provide a reliable water supply shut-off for installations where space is limited.

Product Information

Standard Information

• Manufacturer: Oatey
• MPN: 39134

Technical Specifications

• Box Dimensions: 3-1/4 inches (width) x 2-1/2 inches (depth) x 4 inches (height)
• Face Plate Dimensions: 5 inches (width) x 6 inches (height)
• Material: High impact polystyrene
• Valve Type: 1/4 turn brass ball valve
• Pipe Connection: Soldered
• Applicable Standards: ASME A112.18.1, NSF 61/9, UPC, ISO 9001
• Lead-Free: Yes
