Product Description
The Oatey 37605 is a Moda Quarter-Turn F1960 PEX Connection Washing Machine Supply Box designed for efficient plumbing connections. This supply box allows for easy installation and maintenance in residential and commercial laundry applications.
- Snap-lock design for quick assembly/disassembly
- Includes universal faceplate compatible with all box types
- Pressure rated for 150 psi air and 250 psi water
Product Highlights
Features a dual box design for stacked washer/dryer setups and prevents supply/drain crossover.
Product Information
Standard Information
Technical Specifications
-
Item Name: Outlet Box
-
Connection Size: 1/4 inch
-
Connection Type: F1960 PEX (Brass)
-
Number of Valves: 2
-
Material: PVC Outlet Box, C37700 Forged Brass Valve Body
-
Pressure Rating: 150 psi Air, 250 psi Water
-
Drain Placement: Center Drain
-
Includes: (2) Side Brackets, (2) Faceplates, (2) Sticker Covers, Test Plug, Center Support
-
Height: 6.45 inches
-
Width: 14.13 inches
-
Depth: 4.63 inches
-
Applications: For residential or commercial applications
-
Standards/Approvals: ASME A112.18.1/CSA B125.1, ASSE 1010, IAPMO Listed, NSF/ANSI 61 and 372, PS-54
