Oatey 262048 Oatey Cherne 4 In. Muni-Ball Plug With 3/4 In. Bypass

Product Description

The Oatey Cherne 4 in. Muni-Ball Plug, MPN 262048, is a pneumatic plug designed for sealing the end of four-inch pipes while allowing air or liquid to pass through a three-quarter inch bypass. This plug is useful for testing and monitoring piping systems in both residential and commercial applications.

• Features a three-quarter inch bypass for effective testing and monitoring.
• Suitable for residential or commercial piping installations and repairs.
• Seals four-inch pipe ends and is designed for pneumatic operation.

Product Highlights

This product supports reliable sealing for various piping applications.

Product Information

Standard Information

• Part Number: 262048
• Nominal Size: 4 in. (100 mm)

Technical Specifications

• Bypass Diameter: 3/4 in. F
• Chain Eye Bolts: 1/4 in. (1)
• Deflated Diameter: 3.13 in. (80 mm)
• Deflated Length: 8 in. (203 mm)
• Inflation Pressure: 40 psi (2.8 bar)
• Inflation Thread: Molded in Valve
• Maximum Back Pressure: 22 psi (1.5 bar)/50 ft (15 m)
• Usage Range: 3.25 in. - 4.25 in. (83 - 108 mm)
• Weight: 1.5 lb.
• Material: Rubber
• Type: Pneumatic
