O-Z/Gedney B-100 Type B Conduit Bushing 1 in Trade

Product Description

The O-Z/Gedney B-100 is a Type B Insulated Bushing designed for protecting wires and cables at entry and exit points of threaded rigid conduit and IMC. This product is made of malleable iron and features a zinc plated finish. It is rated for a maximum temperature of 150 degrees Celsius and has an outside diameter of one and five-eighths inches, with a width of three-quarters of an inch.

• Material: Malleable Iron
• Finish: Zinc Plated
• Connection Type: Threaded

Product Highlights

This bushing helps to prevent abrasion during wire pulling, and it creates a voltage gradient to minimize electrical and mechanical stress. It is UL listed and certified, ensuring compliance with standard safety regulations.

Product Information

Standard Information

• Brand: O-Z/Gedney
• Manufacturer: Emerson Electric

Technical Specifications

• Size: 1 IN
• Type: Type B Insulated Bushing
• Finish: Zinc Plated
• Weight: 0.18 lbs
• Applications: For threaded Rigid/IMC conduits
• Temperature Rating: 150 degrees Celsius
• Third Party Certifications: UL File Number E-11853, CSA 011584
