Nvent SCH20B Strut Clamp 1-1/4 inches EMT 1 inches Rigid

Product Description

The NVENT SCH20B is a strut clamp designed for cable and conduit applications. This one-piece clamp features a protective boot and fits into the open side of a strut channel. Installation requires only a screwdriver or nutdriver, eliminating the need for screws or bolts. It is suitable for 1-1/4" EMT and 1" rigid conduit.

• One-piece cable/conduit clamp with protective boot
• No screws or bolts to drop
• Requires only a screwdriver or nutdriver for installation

Product Highlights

One-piece strut clamp with protective boot, easy installation, fits into open side of strut channel.

Product Information

Standard Information

• Brand: NVENT
• Manufacturer Part Number: SCH20B
• Country of Origin: US - United States

Technical Specifications

• Material: Steel
• Finish: Electrogalvanized
• Outer Diameter (OD): 1.000" - 1.51"
• EMT Conduit Size: 1 1/4"
• Rigid Conduit/Pipe Size: 1"
• Static Load 1 (F1): 200lb
• Ultimate Static Load 2 (F2): 75lb
• Ultimate Static Load 3 (F3): 50lb
• Conduit Size: 1 in, 1-1/4 in
• Load Capacity: 200 lb
• Mounting Type: Channel
• Outside Diameter: 1 to 1.51 in
• Series: SCH2
• Size: 1"
• Suitable For Use With: Cable and Conduit
• Type: Clamp
• Applications: Datacom and Low Voltage, Electrical, HVAC, Plumbing and Refrigeration
• Standard: CULus
• Trade Size: 1, 1-1/4 Inch
• Sub Brand: CADDY
• Use With: 1.00 to 1.51 in. O.D. Cable, 1-1/4 in. EMT or 1 in. Rigid Conduit
• Brand: NVENT CADDY
• MPN: SCH20B
• Manufacturer: nVent
