Nvent NVENT-C14H2000GN Type C Slotted Strut Channel 20 Ft

Product Description

The NVENT NVENT-C14H2000GN is a Type C slotted strut channel used for structural support framing in mechanical, electrical, and plumbing installations. Manufactured from steel with a painted green finish, this channel measures 20 feet in length, 1.625 inches wide, and 0.8125 inches tall at 14-gauge thickness. The slotted design allows for flexible positioning of hardware, hangers, and fittings along the full length of the channel. It is handled and installed by licensed electricians, plumbers, pipefitters, and mechanical contractors in both commercial and industrial applications where code-compliant support framing is required.

This strut channel is suited for supporting conduit runs, pipe hangers, HVAC equipment, cable tray, and other mechanical systems in new construction and retrofit projects. The green painted finish provides a standard level of corrosion resistance appropriate for dry and semi-protected interior environments. At 14 gauge, the channel wall provides solid rigidity for medium-duty structural framing applications. It is commonly installed in mechanical rooms, electrical rooms, and overhead framing assemblies where adjustable support positioning is needed.

Key Features

• Type C slotted profile allows flexible hardware and fitting placement along the full 20-foot length
• 14-gauge steel construction provides rigidity for medium-duty framing and support applications
• Painted green finish for standard interior corrosion resistance
• 1.625 inches wide by 0.8125 inches tall channel profile fits standard Type C strut hardware and fittings
• 20-foot length reduces the number of splices needed on long runs

Compatibility

Designed as an OEM-style replacement and standard-fit option for Type C strut channel framing systems using 1.625 inches by 0.8125 inches profile hardware, fittings, and hangers.

Installation Notes

Strut channel installation is typically performed by licensed electricians, plumbers, or mechanical contractors in accordance with applicable NEC, IPC, or IFGC support-spacing requirements. Power down all nearby electrical systems before working in energized panels or conduit spaces. Use appropriate cutting tools for steel framing and deburr cut ends before installing hardware to prevent damage to fittings and personal injury. Secure channel to structural members using rated fasteners appropriate for the load and substrate.

Technical Specifications

• Strut Type: C
• Profile: 1.625 inches wide x 0.8125 inches tall
• Length: 20 feet
• Gauge: 14 GA
• Material: Steel
• Finish: Painted
• Color: Green
• Slot Type: Slotted

Standard Information

• Brand: NVENT
• Manufacturer Part Number: NVENT-C14H2000GN
