nVent Nuheat FG0633 Nuheat N2C240 240V 12.1A 2905W Floor Heating Cable Kit, 953ft Length, Covers 240ft² using Cable Guides

Product Description

The nVent Nuheat FG0633 is a floor heating cable kit designed for effective radiant heat under various flooring types. This system operates at a voltage of 240 volts with a wattage of 2905 watts, allowing for comprehensive coverage over an area of two hundred forty square feet using only one kit. The cable length is nine hundred fifty-three feet, making it adaptable to various installation layouts.

• Adjustable on-site heating coverage
• Includes redesigned cable guides
• Low-profile cold lead for easier installation

Product Highlights

This floor heating cable provides a reliable solution for warming floors. It is suitable for installation under tile, stone, granite, marble, slate, engineered wood, and laminate flooring.

Product Information

Standard Information

• Catalog Number: FG0633
• Brand: nVent Nuheat

Technical Specifications

• Type: 2-Wire, Grounded
• Length: 953 Foot
• Voltage: 240 Volt
• Wattage: 2905 Watt
• Amperage: 12.1 Amp
• Resistance: 20 ohm
• Conductor Material: Copper
• Insulation Material: ETFE
• Jacket Material: PVC
• Temperature Rating: 105 Deg C
• Number of Conductors: 2; Twisted Pair
• Applications: For Radiant Floor Heating in Residential Tiles, Stone, Granite, Marble, Slate, Engineered wood, Laminate Flooring
