nVent Nuheat FG0626 Nuheat N2C120 240V 5.9A 1427W Floor Heating Cable Kit

Product Description

The nVent Nuheat FG0626 is a floor heating cable kit designed for efficient heating in residential spaces. This cable operates at 240 volts and delivers a power output of up to fourteen hundred twenty-seven watts with a current of five point nine amps. The kit includes a length of four hundred seventy-two feet, which can cover up to one hundred twenty square feet when installed correctly.

• Flexible installation with on-site adjustments
• Low-profile cold lead design
• Compatible with various flooring types

Product Highlights

This heating cable kit offers versatility for both renovations and new constructions. It allows for easy configuration on-site, providing homeowners with a cost-effective heating solution. Suitable for radiant floor heating installations under tile, marble, stone, and laminate floors.

Product Information

Standard Information

• Brand: nVent Nuheat
• Manufacturer: Raychem

Technical Specifications

• Catalog Number: FG0626
• Voltage: 240 Volt
• Wattage: 1427 Watt
• Amperage: 5.9 Amp
• Length: 472 Foot
• Resistance: 40 Ohm
• Conductor Size: 16-18 AWG
• Jacket Material: PVC
