nVent HOFFMAN ASTB400 Splitter Trough Block Assembly 600V 400A 4-600MCM:1/0-250 kcmil

Product Description

The nVent HOFFMAN ASTB400 Splitter Trough Block Assembly is designed for efficient power distribution. This assembly operates at up to six hundred volts and supports a current rating of four hundred amps. It effectively connects feeder branch circuits in splitter troughs. The block comes with a main lug and branch lugs, along with copper and aluminum (CU/AL) connectors that are secured to insulators.

• Rated for six hundred volts and four hundred amps
• Includes main lug and branch lugs for versatile connections
• Made from aluminum for durability

Product Highlights

This splitter trough block assembly is ideal for electrical installations, making it easy to tap into power distribution systems.

Product Information

Standard Information

• Catalog Number: ASTB400
• Manufacturer: nVent

Technical Specifications

• Voltage Rating: 600 VAC
• Main Lug Amps: 125 A
• Wire Capacity: 4 AWG to 600 kcmil, 1/0 AWG to 250 kcmil, 6 to 4/0 AWG, 14 to 3/0 AWG
• Branch Lug Amps: 125 A
• Material: Aluminum
• Conductor Type: Aluminum/Copper
• Country of Origin: Mexico
