Nvent Hoffman ASG6X6X6NK Screw-Cover Pull Box / Enclosure 6 x 6 x 6 in

Product Description

The NVENT HOFFMAN ASG6X6X6NK screw-cover pull box/enclosure is designed for commercial and general industrial applications needing a junction or pull box. The Type 1 enclosure is available in painted or galvanized finishes and comes without knockouts. Accessories are available for flush installations and wiring space extensions. It measures 6 x 6 x 6 inches.

• Unique keyhole screw slots in the cover
• Available with or without knockouts
• Flat, removable covers fastened with plated steel screws

Product Highlights

This steel pull box features a screw cover, grounding provisions and mounting holes for easy installation in power distribution applications.

Product Information

Standard Information

• Brand: NVENT HOFFMAN
• Manufacturer Part Number: ASG6X6X6NK
• Country of Origin: Mexico

Technical Specifications

• Catalog Number: ASG6X6X6NK
• Brand: nVent Hoffman
• Manufacturer: Hoffman
• Type: Pull and Junction Boxes
• Color: Gray
• Depth: 6 in
• Width: 6 in
• Finish: Galvanized
• Height: 6 in
• Material: Steel
• Standard: CUL Listed Per CSA C22.2 No 40; Type 1; File No. E27525,IEC 60529, IP30,NEMA/EEMAC Type 1,UL 50, 50E Listed; Type 1; File No. E27525
• Sub Brand: Hoffman
• Applications: Power Distribution
• Color Coding: ANSI 61
• Body Thickness: 1.52 mm
• Number of Screws: 2
• Country of Origin: Mexico
• Made in USA: No
• Item Type: Pull and Junction Boxes
• Series: A90P1
• Mounting Type: Flush
• Cover Type: Screw
• NEMA Rating: NEMA 1/IP30
• Material Specification: 16/14/12 Gauge
• Enclosure: NEMA 1, IP30
• Cover Mounting: Screw Cover
• Enclosure Cover Type: Screw Cover
• Nominal Enclosure Width: 6 in
• Enclosure Cover Features: Screw Latch
• Knockouts / No Knockouts: No Knockouts
• Item - Electrical Enclosure: Enclosure
• Metallic / Non-Metallic: Metallic
• Gauge: Body: 16 ga, Door: 16 ga
• Application: Commercial, Industrial
• Approval: UL 50/50E, CUL, CSA C22.2
• Applicable Standard: IEC 60529
• Mounting: Wall
• IP Rating: 30
• Metal Gauge: 12/14/16 ga
• Product Type: Enclosure
• Basic Material: Metallic
• Closure Method: Screws
• Solid / Clear Cover: Solid
• ECCN: EAR99
• UNSPSC: 39121303
• Color Family: Gray
