Nvent Hoffman A36R3612 Enclosure, Type-3R with Screw Cover, Steel 36 x 36 x 12 in

Product Description

The NVENT HOFFMAN A36R3612 is a drip-shield screw-cover, Type 3R enclosure used as a wiring or junction box to protect controls in outdoor applications requiring protection from rain, sleet, snow, or dripping water. It features a slip-on removable cover fastened with plated steel screws and embossed mounting holes. It is suitable for power distribution applications.

• Drip shield top and seam-free sides, front, and back protect from rain, snow, or sleet
• Slip-on removable cover fastened with plated steel screws along bottom edge
• Embossed mounting holes on back of enclosure

Product Highlights

This steel enclosure provides protection from the elements for outdoor power distribution and control applications.

Product Information

Standard Information

• Brand: NVENT HOFFMAN
• Manufacturer Part Number: A36R3612
• Country of Origin: Mexico

Technical Specifications

• Catalog Number: A36R3612
• Brand: nVent Hoffman
• Manufacturer: Hoffman
• Size: 36.00x36.00x12.00 in
• Type: Screw-Cover,Type 3R
• Depth: 12 Inch
• Width: 36 in
• Finish: Galvanized
• Height: 13-3/4 Inch
• Length: 40 Inch
• Material: Steel
• Standard: CUL Listed Per CSA C22.2 No 94; Type 3R; File No. E27525,IEC 60529, IP32,NEMA/EEMAC Type 3R,UL 50, 50E Listed; Type 3R; File No. E27525
• Enclosure: 3R
• Sub Brand: Hoffman
• Product UPC: 78351043440
• 12-Digit UPC: 783510434403
• Applications: Power Distribution
• Color Coding: ANSI 61
• Body Thickness: 12ga
• Country of Origin: Mexico
• Made in USA: No
• Knockouts: Yes
• UPC: 783510434403
• GTIN: 00783510434403
• Item Type: Pull and Junction Boxes
• Cable Entry Size: (4) 3/4 to 1 in, (4) 1/2 to 3/4 in, (1) 1 to 1-1/4 in Knockout Bottom
• Lock: Padlock
• Mounting Type: Wall
• Series: A90S3
• Cover Type: Screw
• NEMA Rating: NEMA 3R/IP32
• Material Specification: 16/14/12 Gauge
• Number of Knockouts: 9
• Knockout Location: (9) Bottom
• Knockout Size: (4) (3/4 to 1 Inch), (4) (1/2 to 3/4 Inch), (1) (1 to 1-1/4 Inch) Concentric Knockout Bottom
• Service Type: Outdoor
• Approval: UL 50/50E, CUL, CSA C22.2
• Applicable Standard: IEC 60529
• ROHS Compliant: True
• IP Rating: 32
• Metal Gauge: 12/14/16 ga
• Enclosure Cover Type: Screw On
• Material of Enclosure: Carbon Steel
• Closure Method: Screws
• Solid / Clear Cover: Solid
• Enclosure Cover Features: Screw Latch
• Nominal Enclosure Width: 36 in
• Metallic / Non-Metallic: Metallic
• Item - Electrical Enclosure: Enclosure
• Mounting: Wall
• Bulletin Number: A90S3
• Article Number: 43440
• Door Thickness: 12ga
• Knockouts Included: Yes
• Knockout Pattern: A-B-C-D-E-F-G-H-I
• Cover Mounting: Screw Cover
• Cover Latching: Screw
