nVent GR1181GPLUS ERICO ONE SHOT MOLD HORZ. 8AWG TO 3/4 VERT. GRD ROD

Product Description

The nVent ERICO CADWELD GR1181GPLUS is a one-shot type weld metal mold. It is designed for connecting an eight AWG concentric or six AWG solid conductor to a three-quarter inch ground rod. This product uses a single-use ceramic mold instead of traditional graphite molds, which simplifies the welding process. This mold produces a reliable and permanent connection that resists loosening or corrosion.

• Single-use ceramic mold
• Produces a secure connection
• Compatible with various types of ground rods

Product Highlights

This mold is highly effective for grounding applications. It ensures fast and consistent connections in various electrical installations.

Product Information

Standard Information

• Manufacturer: nVent
• UPC: 78285656615

Technical Specifications

• Application: Line Construction Material Applications
• Conductor Size: 8 AWG Concentric, 6 AWG Solid
• Connection Type: Cable to Ground Rod
• Manufacturer Part Number: GR1181GPLUS
• Material: Ceramic
• Mold Price Key: 1
• Rod Size: 3/4 in
• Specifications: Vertical ELL Horizontal Cable
• Standards/Approvals: cULus Listed, NEC Certified, ANSI/UL 467 UL File No. KDER.E220029, cULus File No. KDER7.E220029, CSA C22.2 File No. 41
• Type: 1-Shot Type GR Plus
