nVent CSD12126 HOF Solid Door Enclosure

Product Description

nVent CSD12126 is a solid door enclosure designed for machine control applications. This enclosure measures twelve inches in length, twelve inches in width, and six inches in depth. It features a concealed hinged cover and is rated NEMA 4/12, making it suitable for various environments.

• Application for machine control
• NEMA 4/12 rated for diverse settings
• Durable steel construction with a polyester powder finish

Product Highlights

This enclosure provides reliable protection for sensitive electrical components. It comes with a quarter-turn latch for secure closure and an easy wall mount design.

Product Information

Standard Information

• Manufacturer: nVent
• MPN: CSD12126

Technical Specifications

• Application: Machine Control Applications
• Color: Gray
• Cover Type: Concealed Hinged
• Depth: 6 inches
• Finish: Polyester Powder Painted
• Includes: Panel Mounting Nuts, Panel Grounding Hardware, Sealing Washers
• Length: 12 inches
• Lock: Quarter Turn Latch
• Material: Steel
• Mounting Type: Wall
• NEMA Rating: NEMA 4/12
• Panel Size: 10.2 inches W x 10.2 inches H
• Series: CW1
• Standards/Approvals: cUL Listed per CSA C22.2 File No. 94, RoHS Compliant, VDE Approved, UL 508A
• Type: 1-Door
• Width: 12 inches
