Nvent CCS2ESTLG Swivel Tilt 90 Degree Elbow

Product Description

The NVENT CCS2ESTLG is a swivel tilt 90-degree elbow fitting designed for conduit installations where a fixed elbow cannot accommodate directional variation. The swivel tilt design allows the elbow to pivot and adjust its angle during installation, reducing the need for multiple rigid fittings or custom bends. This type of fitting is commonly found in electrical raceway systems and is installed by licensed electricians working on commercial or industrial conduit runs where routing flexibility is required.

This fitting is suited for conduit installations in commercial and industrial environments where runs must navigate around structural elements, equipment, or other obstructions. The swivel tilt mechanism provides adjustability at the elbow joint, making it practical for overhead, wall-mounted, or floor-level conduit routing. Electricians use this fitting to simplify layout planning and reduce the number of field bends required on a job.

Key Features

• Swivel tilt design allows angular adjustment at the elbow joint during installation
• 90-degree elbow configuration for right-angle conduit transitions
• Reduces the need for custom field bends or additional fittings
• Suited for commercial and industrial conduit raceway applications

Compatibility

Designed as an OEM-style replacement or direct-install fitting for standard conduit raceway systems. Verify conduit trade size and system series compatibility before installation.

Installation Notes

Installation should be performed by a licensed electrician in accordance with applicable NEC requirements and local electrical codes. De-energize all circuits in the affected conduit run before beginning work. Ensure the swivel joint is fully locked into the desired angle before securing the fitting to the raceway. Do not exceed the conduit fill limits specified by the NEC for the conduit trade size in use.

Technical Specifications

• Weight: 7.1 pounds
• UPC: 78351041899

Standard Information

• Brand: NVENT
• Manufacturer Part Number: CCS2ESTLG
