nVent CADDY MCS101 MC/AC Cable Support Bracket, 10-3 to 8-3 MC/AC, 7 Cable

Product Description

nVent CADDY MCS101 is a cable support bracket designed for securing MC/AC cables in various electrical applications. This support bracket accommodates cables ranging from 12/3 to 8/3 AWG, providing efficient organization and support. The bracket is made of steel and finished with electro-galvanization to ensure durability and resistance to corrosion.

• Supports up to seven cables for effective cable management
• Suitable for various sizes of MC/AC cables
• Simple installation and reliable performance in electrical systems

Product Highlights

This product neatly isolates and secures multiple MC/AC cables, helping to prevent bundling issues and maintain compliance with NEC and CEC regulations.

Product Information

Standard Information

• Manufacturer: nVent
• Brand: nVent CADDY

Technical Specifications

• Catalog Number: MCS101
• Material: Steel
• Finish: Electro-galvanized
• Application: Electrical Fixing and Fastening
• Country of Origin: United States
• Standards/Approvals: cULus Listed, NEC Certified, CEC Certified
• Suitable for Use With: 12/3 to 8/2 AWG Isolated Ground Cable, 12/3 to 10/2 AWG Super Neutral Cable, and 10/3 to 8/3 AWG MC/AC Cable
• Special Features: Supports up to 7 cables
